General

Frequency Range*

VHF: 136MHz~174MHz

UHF: 350MHz~400MHz

400MHz~470MHz

450MHz~512MHz

Channel Capacity

512

Channel Spacing

12.5KHz / 25KHz

Operating Voltage

13.6 V DC ± 15% / 88~264V AC 50/60Hz

Duty cycle

Continuous

Current Drain

Standby:

<1.8A

Receive:

<2.5A

Transmit:

<13A

Frequency Stability

±2ppm @ -30℃~+60℃

Operating Temperature

-30℃~+60℃

Antenna Impedance

50Ω

Antenna connector

Type-Nx2(50Ω)

Dimensions (L×W×H)

310mm ×190mm ×362mm

Weight

11kg

LED Indicators

Battery On, Tx, Rx, RPT, OPT, Setup

Transmitter

RF Power Output (Conducted)

25W/50W (VHF)

25W/45W (UHF)

Modulation

8K5ΦF3E / 16KΦF3E

Radiated spurious emission(dB)

70dB

FM Noise

≥45dB(Wide)     ≥40dB(Narrow)

Modulation Distortion

≤3%

Receiver

Sensitivity(12dB SINAD)

<0.35uV

Selectivity

≥70dB (wide)    ≥60dB (narrow)

Intermodulation

≥70dB

Spurious Response Rejection

≥75dB

S/N

≥45dB (wide)     ≥40dB (narrow)

Rated Audio Power Output

5W (Internal)   13W (External @ 4Ω)

Rated Audio Distortion

≤3%(3W)   ≤10%(5W)

Duplex Operation

Receiver Desensitization

≤3dB

Receiver Spurious Rejection

≥67dB

*Radio Dependent, Crossband Model is Available.
