1. New ergonomic design for comfortable operation;

2. Channels and volume are adjustable per actual need;

3. LCD display for radio status minitoring;

4. Complied with IP54 standard.

Speaker specifications:

1) Sound pressure level: 97±3dB (300 to 3000Hz average 1W, 30cm)

2) Impedance: 20Ω±15%@1kHz

3) Power: 2W(rated) /3W(max)

Microphone Specifications:

1) Sensitivity: -23±2dB@1kHz 3v 4.2k 0dB=1v/Pa

2) Output Impedance:  ≤2.2kΩ

Operation Temperature: -30 to 75°C

Storage Temperature: -40 to 85°C

PTT key life ≥ 100000

IP class: IP54
